AC Infinity CLOUDRAY S9 GEN 2 Clip Fan 225 mm, EC motor, automatic oscillation

A next-generation clip fan designed from the ground up for optimal air circulation at all stages of plant growth. It uses a state-of-the-art EC motor with PWM control to provide a wide range of fan speeds, from a gentle breeze to a powerful airflow. The 10 speed settings are shown on a round LED display, which dims after the speed setting has been adjusted so as not to disturb the plant's light cycle. The adjustable tilt of the fan and the swivelling arm give you flexibility in directing the airflow. The heavy-duty clamp can be attached to tent poles of all sizes for a secure vertical hold. Each unit is IP-44 rated, making it highly resistant to moisture and extreme temperatures. Power is supplied via a standard socket with a 2.4-metre power cord. This product is part of the UIS platform of grow equipment and smart controls designed to be combined with each other to create an ideal environment.

Smart control

Equipped with a state-of-the-art electronically commutated (EC) motor that is digitally controlled with precise electron pulsations. Thanks to PWM technology, the fan can utilise the entire speed range from 0 to 100%. Set the optimal air circulation for each stage of your plants' growth, from an ultra-gentle breeze for seedlings and cuttings to a strong airflow for the vegetation and flowering stages. The scope of delivery includes a wired adapter that can be used to connect to the intelligent AC Infinity controllers, enabling targeted control of the climate, growth cycles, time control and much more. The controllers are available separately.

Ideally suited for grow environments

This series was developed from the ground up for use in grow spaces. All components are specially insulated to IP-44 standard to ensure high resistance to liquids and dust. This allows the system to achieve maximum performance and a long service life even in more difficult environments with high humidity and high temperatures.

Details at a glance

• The next-generation clip fan has been redesigned for longer-lasting, targeted air circulation in the grow tent.
• The larger, brushless EC motor with carbon steel gearbox and IP44 protection has been redesigned to maximise the life of the oscillation.
• 10 oscillation levels allow you to focus on specific areas or achieve wide coverage while avoiding obstacles.
• 10 speeds and 10 dynamic wind modes simulate outdoor airflow for optimal plant growth.
• Connects to UIS controllers for control via WiFi app and access to climate triggers, timers and advanced automation.
• Fan impeller: 225 mm | Airflow: Up to 688 m³/h | Automatic oscillation | Suitable for all tent pole sizes

Technical data:

• Blade size: 23 cm
• Dimensions: 26.5 x 35.2 cm
• Total airflow: 688 m³/h
• Noise level: 35 dBA
• Static air pressure: 25 Pa
• Electrical voltage: 100 - 240 V (50/60 Hz)
• Power: 11 W
• Current: 0.05 A
• Power plug: Euro plug
• Power cable: 244 cm
• Humidity range: 35 - 85 % RH
• Temperature range: 0 - 60°C
• Protection class: IP-44
• Swivel range: 90
• Tilt angle: 55
• Oscillation: Automatic oscillation
• Fan bearing: Double ball bearing
• Installation position: Horizontal or vertical
• Certifications: CE, RoHS, ETL
