PrimaKlima Extractor Fan PK100EC-TC 580m³/h speed/temperature control

PrimaKlima developed a new highlight on the market: the PK100EC-TC circular in-line fan, which persuades with its high-quality manufacture, its energy efficiency, and a very silent service performance. The circular in-line fan contains a temperature control, as well as an integrated speed control, which is not only practical, but also puts aside the need to buy an optional speed control.

The integrated EC-motor by Ziehl-Abbeg (made in Germany) stands out through its low power consumption, high pressure generation, performance, and it is very silent in operation. The integrated speed control enables a continuous adjustment of the service performance and all that without any annoying humming noises.

The built-in speed control is adjusted to approximately 360 cbm/h (approx. 22watt power input) ex factory. With those adjustments volume, performance, and power consumption are in an optimal range. The maximum performance can be infinitely adjusted by a small screwdriver on the outside of the housing. At dimmed state the fan only uses the energy that corresponds to its revolution speed. The automatic temperature control completes the fan: simply set the desired room temperature (20 - 30°C) and the temperature control will do the rest.

Advantages at a glance:

• EC-Technology: electricity savings of up to 70% depending on the contamination in comparison to the AC version
• Super silent operation due to modern EC-technology
• Finally no more humming noises during the complete speed range
• Temperature-independent switch between 2 speed level
• Maximum speed is adjustable with a trimmpotentiometer. Ex factory adjusted to 360m³/h at an electricity consumption of 22watt
• The expected lifetime of the motor is > 12 years
• The top-class 115 watt EC motor by Ziehl & Abegg, max. performance 580m³/h, pressure 100mbar

Technical detail:

• Voltage: 230 Volt 50/60 Hz
• Power input: 115 Watt / 0,5A (rotation speed dependent)
• Output: max. 580 cbm/h
• Pressure max.: 1000 Pa
• max. operational temperature: 50 °C
• Diameter: 100mm
• Power plug approx. 2 Meter long
• Temperature sensor cable approx. 2 Meter long
• Weight: ca. 2,38 Kg
